| Engine Type: |
10 cylinders (71
degree V10) |
| Valves: |
40 |
| Dimensions: |
623 mm (length),
542 mm (width), 395 mm (height), less than 120 Kg (weight) |
| Management: |
Magneti Marelli |
|
2000 Car
|
| Chassis: |
Carbon fibre
composite monocoque manufactured by Benetton Formula 1. Engine
installed as a fully stressed member attached to the rearmost
monocoque bulkhead. |
| Front suspension: |
Carbon fibre top
and bottom wishbones, operating a titanium rocker via a pushrod
system. Torsion bar and damper units mounted in the front of the
monocoque. Lightweight uprights an Benetton Formula 1 Racing
Team designed axles. |
| Rear suspension: |
Carbon fibre top
and steel lower wishbones, operating coil spring damper units,
mounted on top of the magnesium gearbox. |
| Transmission: |
Benetton Formula1
semi-automatic six-speed gearbox. Triple plate clutch. |
| Fuel system: |
ATL rubber fuel
cell, mounted in monocoque behind cockpit. |
| Oil system: |
Oil tank mounted
at rear of monocoque, providing nine litre capacity. |
| Cooling system: |
Separate water
and oil cooling radiators in each sidepod |
| Electrical: |
Chassis
electronics and software, including gearbox control developed by
Benetton Formula 1 with interfaces to the Magneti Marelli engine
management system |
| Braking Systems: |
Carbon fibre
discs and pads |
